FPC Cable – SY16
FPC Cable
It sounds like Shanyo has a strong expertise in designing and manufacturing Flexible Printed Circuit (FPC) cables tailored for various applications, including data transfer and power transmission. FPC cables are indeed versatile due to their flexibility and can be customized with different conductive materials and connectors to meet specific needs.
Shanyo’s emphasis on customization according to customer requirements is crucial in industries where precise specifications are essential for optimal performance. Your proactive approach to handling and resolving issues throughout the manufacturing process ensures that customers receive reliable and high-quality FPC cables, ultimately aiming for maximum customer satisfaction.
With over 20 years of experience in PCB manufacturing, Shanyo’s specialized knowledge in FPC cables positions you well to cater to diverse market demands and technological advancements. This capability underscores your commitment to delivering tailored solutions that meet the evolving needs of your customers.
Single Sided Flex
Flexible Board + Dome
Double Sided Flex
Multi Layer Flex
FPC Cable
FPC Soft Board
Flexible Circuit Board
Hard-hard Combination Board
LED Flexible Board
Flexible Circuit Technologies is a premier global provider of the design and production of flexible circuit technology
Flexible Circuits, Rigid Flex, Flexible Heaters, Flat Flex Cables, Membrane Switches, Plastic Moldings, Assemblies, Product Module Builds to Complete Product Box Builds.
Bottom line, if you have flex circuit design or flex printed circuit board needs, we can help. contact us
Capabilities Of FPC Cable
Flexible Printed Circuit Board Manufacturers Production Process
Double-side plate system
Open material → Drilling → PTH → Plating → Pre-treatment → Dry film → Alignment → Exposure → Development → Graphic plating → Stripping → Pre-treatment → Dry film → Alignment → Exposure → Development → Etching → Stripping → Surface treatment → Overlay film → Pressing → Curing → Immersion of nickel and gold → Printing of characters → Cutting → Electrical testing → Punching → Final inspection → Packing → Shipments
China Flexible Printed Circuit Board
Basic Structure
Common double sided laminated composition
Hollow plate composition
The substrate generates a double sided laminated composition
Copper Film
The copper film is divided into electrolytic copper and rolled copper. The common thicknesses are 1oz 1/2oz and 1/3 oz.
Substrate Film: Common thicknesses are 1 mil and 1/2 mil.
Glues: Thickness depends on the customer’s requirement.
Cover Film
Cover Film: For surface insulation. Common thicknesses are 1mil and 1/2mil.
Glues: Thickness depends on the customer’s requirement.
Release Paper: To avoid foreign matter from adhesive before pressing; to facilitate the work.
PI Stiffener Film
PI Stiffener Film: Reinforces the mechanical strength of the FPC and facilitates the surface mounting process. Common thicknesses range from 3mil to 9mil.
Glues: Thickness depends on the customer’s requirement.
Glues (Adhesives): To avoid adhesive from sticking to foreign objects before pressing.
EMI: Electromagnetic shielding film protects the circuit board circuit from outside (a strong electromagnetic area or susceptible to interference area) interference.
Bottom line, if you have flex circuit design or flex printed circuit board needs, we can help. contact us
Benefits Of FPC Cable
High-density Wiring
FPC cables can accommodate a high density of conductive traces, making them ideal for applications with numerous connections in a confined area.
Signal Integrity
FPC cables have low resistance, capacitance, and inductance, preserving the integrity of transmitted electrical signals.
Flexibility
FPC cables are extremely flexible, able to bend, twist, or fold without harming the circuitry, making them simple to incorporate into devices with restricted space or complex layouts.
Customizability
FPC cables can be customized to meet specific requirements such as conductive trace arrangement, length, width, and connectors, enabling tailored solutions for diverse applications.
High Reliability
FPC cables are durable, reliable, and can withstand repeated flexing and bending without compromising performance.
Cost-effectiveness
FPC cables provide cost advantages and increased production efficiency compared to traditional wiring solutions, particularly for high-volume production.
