EMI Single/Double Layer Dome Array
Features：
Strong adaptability to changing climate；
It has the function of protecting the circuit when static electricity penetrates;
Compared with existing single-layer or double-layer conductive films, the manufacturing process is more complex;
On the existing metal dome switch, EMI printing is used to control the impedance of the printing surface below 5.02Ω, so that it can produce the blocking effect of electromagnetic waves and static electricity to achieve the effect of floating sound quality;
Advantage：
OEM / ODM
Free sample
Fast delivery
Good quality
24 hours online service
Factory direct sales wholesale
Support customization (color/ shape/ size/ material)
There is a layer of silver paste printed on top of Myalr (viewed from the front of the product) – that is, ESD (Electrostatic Discharge Control). EMI is mainly used to prevent static electricity generated by electronics and peripheral products from damaging target electrical appliances. It is a PET film Top that provides EMI/RFI shielding.
EMI printed conductive film To prevent static electricity from damaging the conductive film, conductive films used in some special fields such as mobile phones need to print a layer of silver paste or silver carbon oil on the Mylar layer with elastic sheets, which is called ESD, enhanced Electromagnetic compatibility.
EMI Single/Double Layer Dome Array
Advantages Showcase
METAL DOME SHEET ASSEMBLY METHOD
Metal Dome Array! Widely used
This product is extensively used in various electronic devices, such as mobile phones, cameras, computers, remote controllers, printers, game consoles, smart wearables, financial terminals, medical equipment, mechanical devices, sports gear, home appliances, automotive electronics, and more.
Metal Dome Button remote control
Remote Control Buttons Metal Dome
PC Button Metal Dome
PS Remote Control Dome Array
Car Button Metal Dome
Industrial Equipment Control Panel Dome Array
Satellite Phone (Intercom Keys) DOME SHEET+ UV Bumps
Remote Control DOME SHEET+ UV Bumps
Electronic Equipment DOME SHEET+ UV Bumps
PS Remote Control DOME SHEET+ UV Bumps
Automobile Industry DOME SHEET+ UV Bumps
Medical Equipment DOME SHEET+ UV Bumps
Metal dome design principle
Shanyo’s ISO 9001 quality management system certification ensures excellence. A professional design and technical team, gets the drawings to communicate, and determine the plan. Our fast machining capabilities promise quality custom-machined parts delivered within 1 day.
According to the needs of different product structures and grades
x
x
x
x
Dome Array Specifications
- Structure: Double Layers
- Material: Rubber glue + Mylar + Adhesive + Spacer + Adhesive + metal dome
- Color: Mylar: transparent; Spacer: white or transparent
- Thickness: Mylar: 0.05mm; Spacer: 0.075mm
- Available Domes: c-series, F-series, T-series
- Operating & Storage Temprature: 5-125℃
Various specifications of metal domes are available：
- Triangle Metal Dome;
- Cruciform Metal Dome;
- Four Legs Tactile Domes
- Circular/ Round Metal Dome;
- Oblong/ Rectangle Metal Dome;
- Ellipse/ Round Waist Metal Dome;
- Circle / Round Metal Dome With Holes;
- Four Leg Metal Domes with Center Hole；
- Customized metal dome (color/ shape/ size, material, etc.).
Metal dome design principle
Metal Dome Array Classification
- Transparency: Better alignment
- White: generally used with light guides (reflective)
- Black: generally used to block out light (obscuring the content)
- Yellow: it belongs to high-temperature resistant material (can exceed SMT high-temperature effect for a short time)
- Silver screen: grounding anti-static effect Transparency: Better alignment
