Custom Metal Dome Switch Arrays
Features：
Long life
Low cost
High reliability
Easy assembly
Low resistance
Corrosion resistance
Good hand feeling, etc.
Advantage：
OEM / ODM
Free sample
Fast delivery
Good quality
24 hours online service
Factory direct sales wholesale
Support customization (color/ shape/ size/ material)
Dome Array Features:
- Chemical resistance, weather resistance, and damage resistance;
- Ø 3 to Ø 6 mm, 100 g to 250 g driving force;
- Typical life span is greater than 1M cycles;
- You can choose the version with or without pits.
Dome array advantages:
- Shorten production time and easy assembly
The dome array is easy to assemble, and all domes can be placed on the PCB at the same time to shorten production time. The combination of automated processes will bring extremely low unit costs and improve production efficiency.
- Ensure quality
Dome arrays can reduce quality issues associated with dome placement because these arrays or dome sheets prevent misalignment or misalignment of dome pads, upper domes, and double dome misalignment during assembly.
Shanyo’s offers customized metal dome switch arrays, and pre-installed Mylar carriers with PET on the back. We assemble the dome array according to the drawings you provide and the selected dome style and quantity and cut it according to your specific size and shape. In addition, we can also place metal domes of different sizes, shapes, and strengths on the same array.
We can meet a series of unique customized metal dome requirements, including opening holes for other components on the circuit board. Or, if your application requires a high driving force, we can manufacture a stacked metal dome array(dome sheets). In this configuration, we stack two metal domes together in each position.
Advantages Showcase
METAL DOME SHEET ASSEMBLY METHOD
Placing Custom Dome Arrays
Shanyo’s can also provide custom placement equipment to make the placement of metal dome arrays easier and more accurate. Custom placement equipment is more affordable and accurate than visual calibration, making array placement simple and easy. To design customized metal dome arrays, we can also provide die-cutting products, 10 imported Korean continuous punching die-cutting machines with very high processing efficiency, and we have successfully developed DOMESHEET and PCB automatic placement equipment to provide one-stop service for our customers. The use of more convenience and simplicity greatly saves costs and improves work efficiency. We need you to provide the following information:
- Drawings/printouts with overall dimensions, dome part numbers, dome locations and die cuts.
- Estimated annual usage.
Metal Dome Array! Widely used
Applied to TV remote controls, air conditioner remote controls, various button facilities, and other equipment.
Metal dome Array(Sheet)
This product is extensively used in various electronic devices, such as mobile phones, cameras, computers, remote controllers, printers, game consoles, smart wearables, financial terminals, medical equipment, mechanical devices, sports gear, home appliances, automotive electronics, and more.
Metal Dome Button remote control
Remote Control Buttons Metal Dome
PC Button Metal Dome
PS Remote Control Dome Array
Car Button Metal Dome
Industrial Equipment Control Panel Dome Array
Satellite Phone (Intercom Keys) DOME SHEET+ UV Bumps
Remote Control DOME SHEET+ UV Bumps
Electronic Equipment DOME SHEET+ UV Bumps
PS Remote Control DOME SHEET+ UV Bumps
Automobile Industry DOME SHEET+ UV Bumps
Medical Equipment DOME SHEET+ UV Bumps
Metal dome design principle
Our Metal Dome Array Machining Services Shanyo’s custom Metal Dome(Snap Dome) services are the solution for engineers, product developers, and designers requiring prototyping and low-volume production. From simple to intricate designs with tight tolerances;
Shanyo’s ISO 9001 quality management system certification ensures excellence. A professional design and technical team, gets the drawings to communicate, and determine the plan. Our fast machining capabilities promise quality custom-machined parts delivered within 1 day.
According to the needs of different product structures and grades
Nickel plating, silver plating, gold plating
x
Smooth contact
x
Strong conductivity
x
Stable rebound
x
Good feel
Dome Array Specifications
- Structure: Double Layers
- Material: Rubber glue + Mylar + Adhesive + Spacer + Adhesive + metal dome
- Color: Mylar: transparent; Spacer: white or transparent
- Thickness: Mylar: 0.05mm; Spacer: 0.075mm
- Available Domes: c-series, F-series, T-series
- Operating & Storage Temprature: 5-125℃
Various specifications of metal shrapnel are available：
- Triangle Metal Dome;
- Cruciform Metal Dome;
- Four Legs Tactile Domes
- Circular/ Round Metal Dome;
- Oblong/ Rectangle Metal Dome;
- Ellipse/ Round Waist Metal Dome;
- Circle / Round Metal Dome With Holes;
- Four Leg Metal Domes with Center Hole；
- Customized metal dome (color/ shape/ size, material, etc.).
Metal dome design principle
How to choose the snap dome chip based on the PCB pad shape
Metal Dome Array Classification
- Transparency: Better alignment
- White: generally used with light guides (reflective)
- Black: generally used to block out light (obscuring the content)
- Yellow: it belongs to high-temperature resistant material (can exceed SMT high-temperature effect for a short time)
- Silver screen: grounding anti-static effect Transparency: Better alignment
- White: generally used with light guides (reflective)
- Black: generally used to block out light (obscuring the content)
- Yellow: it belongs to high-temperature resistant material (can exceed SMT high-temperature effect for a short time)
- Silver screen: grounding anti-static effect
Order Metal Dome Array Machining Parts Online: Easy &Fast
Upload your design file to our Instant Quote Platform and instantly receive pricing, lead time, and DFM details for your dome array components. Specializing in metal dome(snap dome) sheet machining for metals and plastics, we provide adaptive production and shipping solutions to align with your product development needs.
Instant Quotation
Eliminate long waits and reduce uncertainty. With our instant online quotations, you gain clear cost insights immediately, and free & professional DFM feedback, streamlining your Metal Dome Switch, Metal Dome Array, EMI Printing, Metal Dome Array, Light guide plate module, FPC switch, Membrane switch panel, Backlight Module, Equipment, die-cut products, light guides, UV bumps, FPC, panel buttons, PCB circuits, film flexible circuits and Packaging machining decisions.
Online Annotation
Say goodbye to tedious back-and-forths. Directly annotate your 3D drawing online and convey specific changes or queries instantly via live chat. Ensure precise machining requirements are communicated and understood without ambiguity.
All-in-One Project Management
Take full control of your Metal Dome (Snap Dome) projects. Manage both quotes and orders in a unified platform. Effortlessly oversee every project, ensuring that each stage is transparent and easily accessible.
Team Collaboration
Strengthen your metal dome array (metal dome sheet) coordination. Create teams, invite members instantly, and access shared quotes & orders with ease. Include key departments like accounting, ensuring smooth payment oversight and execution.
Services
Why Choose Our Custom Dome Array Machining Service
Online Instant Quote & DFM Analysis
Online Instant quote request email, and get instant Dome Array quotes by simply uploading your design files. We can customize metal domes of various sizes and shapes according to customer requirements. provides real-time & competitive pricing and comprehensive feedback.
Fast and Reliable Delivery
Boasting robust manufacturing capacity, Shanyo’s ensures quick turnaround for tactile dome machined parts. Plus, with our varied dome array(snap dome switch) choices, you’ll get your order on time, without the usual hassles.
Consistent High Quality
Advanced metal dome automatic assembly equipment multi-function testing equipment, and rigorous quality checks, combined with constant communication, ensure that every snap dome you receive meets the highest standards, consistently and reliably.
Professional Engineering Support
No matter where you are, you can get our 24/7 engineering support all year around. Our experienced engineer can provide you with the most appropriate solution for your metal dome customized design, material selection, surface finishing, and even lead time.
COMPANY CORE ADVANTAGE
Share innovation
actively communicate with domestic and foreign counterparts, cooperate, share technological achievements, constantly develop more new products to enrich the product catalog of enterprises, and strive to develop with old and new customers and colleagues in the industry who patronize our company.
Professional
The company specializes in the research development and production of metal shrapnel/pot pan disc and conductive film of metal shrapnel. It has very rich experience and can provide different shrapnel solutions according to customers ‘needs.
Overseas Quality
Since its establishment, it has been keeping pace with the times, improving the quality of metal shrapnel and conductive film of metal shrapnel to meet the harsh requirements of customers all over the world. The reliability and long-term stability of product quality have been continuously praised by foreign customers, and the quality has been rising steadily.
Rich products
from round, cross (four corners), waist round shrapnel to custom shrapnel, from single-layer structure, double-layer structure, EMI printing, Rubber structure.
Strict control
from the purchase of raw materials, mold design and production, product production, quality testing, packaging sales, and other aspects of strict operation by the requirements of ISO 9001:2015, to ensure the consistent reliability of products;
High-quality service
punctual delivery; free technical solutions and samples; quick response customers respond 1 hour after mail receipt; after-sales service 1 hour fast processing.
